Not quite a sizzle reel for the #handheld, but I’m going to start posting videos of games running on this thing. Again not sure how playable games will be over the course of a whole game start to finish but I’ve played each of these for about an hour and they’ve held up.
So I got DM’ed by a troll who claimed that since the #nintendoswitch can play #Skyrim I was really just wasting my time. Now he might be right (from a pure time perspective) but I’ve had fun making this…having said that…here’s some Skyrim since apparently for your #handheld to be “worth it” it’s got to play Skyrim. Started a new game, not sure how smooth it might be FPS wise later on but the intro wasn’t too bad. Note, video is sped up 200%. Sorry for the blue cast on everything, the lighting in my apt isn’t good for video.
TLDR; got done with version 2 of my portable #steammachine based on #florianrenner ‘s awesome #gameboy1up concept… now onto version 2.5!
-Managed to shave off a 1/4″ in the depth and about 1/8″ in the length and width. Unit now measures: 7 3/4″ (197mm) x4 3/16″ (106mm) x1 1/32″ (26mm)
-Installed battery. Version 1’s battery never fit right.
-Xinput instead of Dinput using Zachery Littell’s ( @msf_reaper ) awesome library for the TeensyLC.
-Switch between mouse mode and gamepad mode using a key combination. Similar to the steam controller’s reptile mode.
-Replaced analog volume control with digital
-Buttons locations and sizes tweaked
-Used UV glue to bond the LCD plexi to the screen. Didn’t protect it enough so some of the glue got into the backlight
-Clean up all mistakes on the case
-Add battery management logic, low power notification, etc.
-Continue to tweak button ergonomics
-Create a simplified version to house a raspberry pi and model
-Speakers, I usually use headphones with handhelds so this has been a bit of a lower priority
-Paint the inside of the case a dark color and mask LEDs so they don’t shine through.
Screen size is driving the overall size of the case. It’s pretty large as is but basing it on 5″ doesn’t actually give you all that much volume to work with. I’ve been thinking of making a 7″ version of this which would allow me to use beefier hardware. I’ve got a M7 board that’s dying to get used. Still based around an @intel m3 processor.
So I got as done as I’m going to get for today. As anticipated I’m running on no sleep. Not sure if I finished the portable I was working on last night/this morning as I had just enough time to wire everything up and let my terrible paint job dry enough to be holdable…LIPOs didn’t come in this week so we’ll see if turns on once it’s plugged in. If any of you are coming to #Makerfaire today be sure to say hi 🙂
Convinced myself to do #makerfaire again this year. The realization that I only have 2.5 months to prepare has begun to sink in…. 😰 looking forward to seeing some of you there!
Quick office mini-itx build
